Quick Details

  • Place of Origin: Hebei, China (Mainland)
  • Brand Name: NNT
  • Model Number: ZJ
  • Theory: Centrifugal Pump
  • Structure: Single-stage Pump
  • Usage: mining tailing convey, tunnel solids water, sand water
  • Power: Electric
  • Standard or Nonstandard: Standard
  • Fuel: power or diesel
  • Pressure: Low Pressure
  • Application: sea water, sand water slurry
  • Type: ZJ slurry pump
  • Product name: New type 50ZJ-I-A33 slurry pump factory direct prices
  • Material: High chrome alloy A05
  • Model: 50ZJ-I-A33
  • Inlet/Outlet: 80/50mm
  • Max power: 18.5KW
  • Seal type: Expeller seal or Gland seal
  • Max allowable solid diameter: 13mm
  • Head: 7-46m
  • Capacity: Up to 60m3/h

Packaging & Delivery

Packaging Details: ZJ slurry pump in exporting plywood case or as customer request
Delivery Detail: ZJ slurry pump shipped in 7 days after payment
New type 50ZJ-I-A33 slurry pump factory direct prices
Product Description

ZJ series series sand dredging pump is suitable for handing abrasive corrosive solids bearing slurry with maximum concentrations of wt.45%(ash) and wt.60%(ore). They are widely used in power,metalluragical,mining coal and building materials andother sectors. The ZJ series slurry pumps can be oeprated intandem positation according to the requirements of users. After experts in our country evaluated,they all think that the ZJ series slurry pumps lead their domestic counterparts in various technical performance,with most of the approaching the quality,advanced world level in efficiency.

Features



Mode of structure: Including ZJ ,ZJL series pumps. The outlet diameters of the pumps vary from 600mm to                                                  400mm,350mm,300mm,250mm,200mm,150mm,100mm,80mm,65mm,50mm,40mm,25mm etc.



Structure Features: Pump head: The pump centrally split vertical direction. Discharge port can be positioned at                                              8 different positatio at an intercal 45°.



                                 Support : Centrally split in horizontal direction

                                                 Hanging Bracket



                                 Shaft Seal: Expeller seal and packing seal

                                                    Packing seal and Mechanical seal



Driven patterns:  Direct Driven, Direct driven via hydraulic coupling and Belt driven.



Features of use:  1.high efficiency

                             2.Long service

                             3.steady operation

Materials
 High chrome alloy: A05, A07, A49, etc.
Natural rubber: R08, R26, R33, R55, etc.
Other materials can be supplied as requirements:

Casting, shaft, throat bush, front liner, back liner, wear plate, case, cover, stuffing box, lantern restrictor,

cover plate bolt, volute, throat bush, shaft sleeve, cover plate liner, frame plate liner ,neck ring, expeller ring,

expeller, bearing assembly, volute liner, volute packing, bowl, bearing cartridge, cover plate liner, impeller,

closed impeller, open impeller

Performance



Applications

 Tailings, sugar beet, dredging, slag granulation, cyclone feed, slag granulation, suction hopper dredging, barge loading, mill discharge, sand reclamation, booster pumping, sand waste, material transfer, etc.



Packaging & Shipping

 In plywood box or depend on customer's requirements, shipped in 15 days after deposit payment received

About Nainater





Contact

 Feel free to contact me whenever you need any information about ZJ Slurry pump


Shijiazhuang Nainater Slurry Pump Co., Ltd (NNT Pump)
Website: http://www.nntpump.com
Address: No.1, Yanshan Street, Hi-tech Zone, Shijiazhuang City, Hebei Province, China
If you have any questions ,please feel free to contact with me via Trade Manager ,
Skype or Email . We will reply within 12 hours .
