Quick Details

  • Place of Origin: Hebei, China (Mainland)
  • Brand Name: NNT
  • Model Number: TL(R) series desulphurization pump
  • Theory: Centrifugal Pump
  • Structure: Single-stage Pump
  • Usage: Mining,Dredge,Coal,FGD,Chemical,ect
  • Power: Electric
  • Standard or Nonstandard: Standard
  • Fuel: Diesel
  • Pressure: High Pressure
  • Application: Mining,Dredge,Coal,FGD,Chemical,ect
  • Transfering Material: Ore,Sand,Coal,Slag,Ash slurry,etc.
  • Shaft Seal: Packing seal, Expeller seal, Mechanical seal
  • Cooperation: OEM,ODM
  • Type: 700X-TL Desulphurization Pump for Power Station

Packaging & Delivery

Packaging Details: plywood case ,or depend on customer's requirements
Delivery Detail: Shipped in 14 days after payment

1, Product Name : 700X-TL Desulphurization Pump for Power Station



Brife Introduction

Desulphurization pump is a kind of single stage, single suction horizontal centrifugal pump with hanging

bracket. Pump casing adopts the structure of open behind. Pump is connected with motor or speed regulating mechanism by lengthened flexible coupling. It can be inspected easily without dismounting rotor parts and inlet/outlet pipeline.

Materials



Features

1The pump restricting parts adopt the advanced flow simulation technology to guarantee the reliable pump design and the high operating efficiency.
2The anti-corrosion & anti-wear metal and rubber materials which are specifically developed for FGD pumps have been proved by the practice that, they can ensure the long-life pump operation. Through adjusting the bearing components to change the impeller position in the pump chamber all-time high-efficient operation of the pump can be achieved. The pump is characterized by the back knock-down structure which is simple and advanced.
3It is easy to maintain and repair and it is on need dismantling inlet and outlet water pipes. The containerized mechanical seal specially used for the desulphurization process is adopted and its operation is reliable.



2, Type Notation

600X-TLR

600: Diameter of discharge

X: Bracket Model (bearing lubricating way: diluted oil)

TL: FGD Pump

R: Rubber Liner Code

Samples

600X-TLR: The diameter of discharge: 600mm, bearing lubricating way: diluted oil, Rubber liner.

3, Models and introductions





Type

Capacity (m3/h)

Head (m)

Speed (r/min)

Maximum efficiency η(%)

NPSH

(m)

Outlet diameter (mm)

Inlet diameter (mm)

 350TL(R)

   1600

 25

   960

  82

 4.5

 350

  400

400TL(R)

   2500

 25

   725

  83

  5.0

 400

  450

500TL(R)

   3750

 25

   725

  85

 5.0

 500

  500

600TL(R)

   6300

 25.5

   620

  88

 5.5

 600

  700

700TL(R)

   6840

 26

   485

  87

 6.0

 700

  800

800TL(R)

   9360

 31

   485

  90

 7.0

 800

  900

900TL(R)

   15000

 30

   485

  90

  8.5

 900

  1000

1000TL

   10440

 15

    485

  89

 7.0

 1000

  1200



4, Application

Desulphurization pump applicable industry: flue gas desulfurization(limestone/gypsum wet desulphurization,double alkaline desulfurization,circulating fuidized bed desulfurization,seawater desulfurization and ammonia desulphurization,etc.)



5, Materials Test Machine: Orient Spectrometer





6, Meeting international standards



The quality management systems of Nainater slurry pump are accredited to ISO 9001:2000 and our environmental management systems are accredited to ISO 14001:2004.





7, Related Products



























8, Contact Us
Shijiazhuang Nainater Slurry Pump Co., Ltd (NNT Pump)





Address: No.1, Yanshan Street, Hi-tech Zone, Shijiazhuang City, Hebei Province, China



If you have any questions ,please feel free to contact with me via Trade Manager ,



Skype or Email . We will reply within 12 hours .
